Zigzag machines mechanical
ZOJE ZJ20U93
Zigzag machine - sewing machine head
Description:
Universal 1-needle zigzag machine for light and medium materials. Bottom feed, max. sewing speed 2.000 s.p.m., max. zigzag length 5 mm, max. zigzag width 9 mm, central lubrication. Needle position can be adjusted in one of three starting points (left, center, right).
For this machine we recommend SCHMETZ needles system 135x5 or 135x5 SERV7, with correct needle points, depending on the fabric.
Technical specification:
| Type of sewing material | light, medium |
| Automatic needle positioning | no |
| Max. zigzag stitch width | 9 mm |
| Max. zigzag stitch width | 5 mm |
| Max. stitch length | 5 mm |
| Max. sewing speed | 2000 s.p.m. |
| Needle system | 135x5 |
| Kit | head |
