Sewing machines

2-needle post-bed lockstitch machines

Automatic 2-needle post-bed lockstitch machine with bottom and upper roller feed, with AC Servo motor - complete sewing machine

ZOJE ZJ9620SA-D3-H-N1.8-3 SET

Automatic 2-needle post-bed lockstitch machine with bottom and upper roller feed, with AC Servo motor - complete sewing machine

Compare products

Description:

2-needle automatic post-bed lockstitch machine with bottom roller feed and active roll presser foot (roll on the left side of the needle). With built-in energy-saving AC Servo motor and control panel. Serial equipped with automatic functions: electromagnetic thread trimmer, foot lifter, reverse feeding with programmed size of the initial and final bartack, needles positioning, programming control panel and energy-saving LED lamp for lighting of working field.

For sewing thick fabrics. Designed for sewing in hard to get places in production of sports and leather shoes, fancy leather goods etc.

Needles gauge 1.2-1.8 mm, with possibility to change to 2.0-2.4 mm by changing the needle plate (to be purchased separately). Max. sewing speed 2.000 s.p.m., max. stitch length 3.6 mm, foot lifting up to 7 mm (hand lifter) or 10 mm (foot lifter), post height 17 cm, central lubrication.

Complete sewing machine with Kessler stand and table top.

For this machine we recommend SCHMETZ needles system 134-35 or 134-35 SERV7, with correct needle points, depending on the

Technical specification:

Type of sewing material
Type of feed
Built-in motor (direct drive)
Automatic needle positioning
Automatic thread trimming
Automatic foot lifter
Automatic bartacking
LED lighting of working field
Max. stitch length
Post height
Presser foot lift height
Max. sewing speed
Needle system
Kit
