Sewing machines

1-needle flat bed lockstitch machines with bottom and needle feed

Automatic lockstitch machine, needle feed, light and medium materials, built-in AC Servo motor, control box, closed lubrication circuit - complete machine
Automatic lockstitch machine, needle feed, light and medium materials, built-in AC Servo motor, control box, closed lubrication circuit - complete machine

ZOJE ZJ9903AR-D3B/PF SET

Automatic lockstitch machine, needle feed, light and medium materials, built-in AC Servo motor, control box, closed lubrication circuit - complete machine

Compare products

Description:

Universal 1-needle lockstitch machine, needle feed, for light and medium materials. Serial equipped with automatic functions: thread trimmer, reverse feeding, foot lifter, needle positioning, reverse feeding with programmed size of the initial and final bartack, programming control panel and integrated 3-degree, energy-saving LED lamp for lighting of working field. Machine with increased sewing field (distance between needle bar and machine's arm is 30 cm) and closed, shortened lubrication circuit (dry needle bar) which effectively prevents fabric staining during sewing.

Model with energy-saving AC Servo motor, control box, programming control panel and power switch integrated into machine head (mechatronics "all-in-one" set). Thanks to integration of all elements the machine works quietly and without adverse vibrations. AC Servo motor saves up to 70% energy comparing to a conventional electronic motor or clutch motor. Equipped with vortex fan which sucks the external air and ensures more efficient cooling.

Bottom feed and needle feed (eliminates a problem with shifting of fabric layers to each other - especially when sewing long elements). Max. sewing speed 4.000 s.p.m., max. stitch length 4 mm, foot lifting up to 13 mm.

Complete sewing machine with Kessler stand and table top.

For this machine we recommend SCHMETZ needles system 135x5 or 135x5 SERV7, with correct needle points, depending on the fabric.

Technical specification:

Type of sewing material medium and heavy
Type of feed bottom, needle
Built-in motor (direct drive) yes
Automatic needle positioning yes
Automatic thread trimming yes
Automatic foot lifter yes
Automatic bartacking yes
Wiper yes
Type of lubrication closed "dry" circuit
LED lighting of working field yes
Max. stitch length 4 mm
Presser foot lift height 13 mm
Max. sewing speed 4000 s.p.m.
Needle system 135x5
Kit complete set
