Sewing machines

B9500-13-02 SET 2-needle / 4-thread overlock machine for light and medium materials with mechanic tape metering device. Efficient, quiet and fast.
Now with energy-saving AC Servo motor, control box and power switch integrated into machine head (mechatronics "all-in-one" set). AC Servo motor saves up to 70% Energy comparing to a conventional electronic motor or clutch motor. Ensures quiet work without adverse vibration.

Efficient tape dispenser

Mechanical tape dispenser with adjustable feed speed ZJ-MDK/60 for B9500 overlock series. It will prove useful in many applications, making it easier to work with tapes of various kinds.

ZJ-MDK/60 tape dispenser comes with a foot that allows for precise guidance of tape up to 40 mm (a wider foot can be used for tapes up to 52 mm). It has an adjustable spindle for holding large tape spools and rollers that adjust to the thickness of the tape.

Main features:
- needles gauge 2 mm,
- seam width 6 mm,
- max. sewing speed 7.000 s.p.m.,
- differential bottom feed,
- central lubrication.

A complete sewing machine, on the stand and PREMIUM tabletop of the renowned Kessler brand. The highest quality table top made of 30-layer birch plywood guarantees long life and resistance to working conditions. Covered with structural laminate with increased resistance to impact and abrasion.

For this machine we recommend SCHMETZ needles system B-27 with correct needle points, depending on the fabric.

iNIC-AMzOKM

Close

ZOJE ZJ-B9500-13-PD3-02 SET
900 series is flagship ZOJE overlock series. 2-needle / 4-thread overlock (safety stitch) machine (stitch type 514) for light and medium materials. Serial equipped with automatic functions: thread trimmer with integrated suction for fabric leftovers, pneumatic foot lifter, needle positioning. Equipped with energy-saving LED lamp for lighting of working field.

Model with energy-saving AC Servo motor, control box, programming control panel and power switch integrated into machine head (mechatronic "all-in-one" set). Thanks to integration of all elements the machine works quietly and without adverse vibrations. AC Servo motor saves up to 70% Energy comparing to a conventional electronic motor or clutch motor. Equipped with vortex fan which sucks the external air and ensures more efficient cooling.

Needles gauge 2 mm, seam width 4 mm (6 mm with safety stitch), max. sewing speed 7.000 s.p.m., differential bottom feed, direct drive type needle bar and improved central lubrication.
Compressed air necessary for the trim suction.

For this machine we recommend SCHMETZ needles system B-27 with correct needle points, depending on the fabric.

Close

ZOJE ZJ-B9500-13-PD3-02 SET
2-needle / 4-thread overlock (safety stitch) machine (stitch type 514) for light and medium materials. Serial equipped with automatic functions: thread trimmer with suction for fabric leftovers, pneumatic foot lifter, needle positioning. Equipped with energy-saving LED lamp for lighting of working field.
Overlock equipped with two sensors responsible for raising the presser foot at the beginning of sewing and for automatic thread cutting. This significantly speeds up the work with the machine.

L1Pwb2rCPKY?version=3&loop=1&playlist=L1Pwb2rCPKY

Model with energy-saving AC Servo motor, control box, programming control panel and power switch integrated into machine head (mechatronic "all-in-one" set). Thanks to integration of all elements the machine works quietly and without adverse vibrations. AC Servo motor saves up to 70% Energy comparing to a conventional electronic motor or clutch motor. Equipped with vortex fan which sucks the external air and ensures more efficient cooling.

Needles gauge 2 mm, seam width 4 mm (6 mm with safety stitch), max. sewing speed 7.000 s.p.m., differential bottom feed, direct drive type needle bar and improved central lubrication.
Compressed air necessary for the trim suction.

Ooj7kCInztg

A complete sewing machine, on the stand and PREMIUM tabletop of the renowned Kessler brand. The highest quality table top made of 30-layer birch plywood guarantees long life and resistance to working conditions. Covered with structural laminate with increased resistance to impact and abrasion.

For this machine we recommend SCHMETZ needles system B-27 with correct needle points, depending on the fabric.

atSEhq_9lYk?version=3&loop=1&playlist=atSEhq_9lYk

Close

ZOJE B9500-181-02 SET is mechatronic 2-needle, 4-thread overlock for sewing light and medium fabrics. Sewing machine equipped with back latching device for overlocks.

_ie9uDHdLoo?version=3&loop=1&playlist=_ie9uDHdLoo

Industrial overlock from the new ZOJE - V Generation .

Four-thread overlock

Zoje B9500-181-02 SET is a modern sewing machine equipped with a black latching device. The tackle secures overlock chain, which makes the seam more durable and resistant to being ripped. The basic parameters of this model are: sewing speed - 7,000 stitches per minute , the overlocking width is - 6 mm, needle gauge - 2 mm . The presser foot in this overlock lifts up to a height of the 6 mm. This two needle overlock has a central lubrication system, bottom differential feed and automatic needle positioning .

A modern two needle overlock

Zoje B9500-181-02 SET is an energy-saving sewing machine with an AC SERVO motor built into the head. The machine has an integrated structure - the motor and control box are built into the head. As a result, the sewing machine works quietly and without unwanted vibrations. Zoje overlock B9500-181-02 is serially equipped with LED lighting for the work area and a practical control panel .

A complete sewing machine, on the stand and PREMIUM tabletop of the renowned Kessler brand. The highest quality table top made of 30-layer birch plywood guarantees long life and resistance to working conditions. Covered with structural laminate with increased resistance to impact and abrasion.

For this overlock, we recommend SCHMETZ system B-27 needles with properly selected points.

Close

Zoje B9500-70-02 is professional overlock sewing with a wide five-thread stitch - type 516. Sewing machine with automatic needle positioning and bottom differential feed.

Industrial Zoje overlock

Model B9500-70-02 is characterized by the speed - up to 7000 stitches per minute and the stitch width - overedging width is 5 mm and the gauge of the needles is 5 mm. The total stitch width is 10mm. The foot can be raised to a height of 6 mm. This overlock model is equipped with central lubrication.

Modern five-thread overlock

Sewing machine Zoje B9500-70-02 is a model with an integrated structure. In order for the machine to work quietly and steadily, the motor, control box and drive of the needle bar are built into the head. The use of an effective AC SERVO motor allows for high energy savings. Overlock also has built-in practical lighting of the work area.

For this model we recommend needles SCHMETZ system B-27 with properly selected points.

Close

2-needle / 4-thread overlock (safety stitch) machine (stitch type 514) for medium materials. Equipped with energy-saving AC Servo motor built-in into machine head and automatic needle positioning (top - bottom). AC Servo motor saves up to 70% energy comparing to a conventional electronic motor or clutch motor. Ensures quiet work without adverse vibration.

Needles gauge 2 mm, seam width 4 mm (6 mm with safety stitch), max. sewing speed 6.500 s.p.m., differential bottom feed and top feed - ensures accurate guiding of the upper layer of material, eliminates the problem of sewing over cross seams. Direct drive type needle bar and central lubrication. Stitch length (density) adjustable by special mechanism. It has a differential adjustment in the range of 0.8-1.4 mm.

A complete sewing machine, on the stand and PREMIUM tabletop of the renowned Kessler brand. The highest quality table top made of 30-layer birch plywood guarantees long life and resistance to working conditions. Covered with structural laminate with increased resistance to impact and abrasion.

For this machine we recommend SCHMETZ needles system B-27 with correct needle points, depending on the fabric.

Close

ZOJE ZJ-B9500-13-02 SET
2-needle / 4-thread overlock machine for light and medium materials with pneumatic chain cutter integrated with pneumatic suction device. Efficient, quiet and fast.
Now with energy-saving AC Servo motor, control box and power switch integrated into machine head (mechatronics "all-in-one" set). AC Servo motor saves up to 70% Energy comparing to a conventional electronic motor or clutch motor. Ensures quiet work without adverse vibration.

Main features:
- needles gauge 2 mm,
- seam width 6 mm,
- max. sewing speed 7.000 s.p.m.,
- differential bottom feed,
- horizontal pneumatic type chain cutter,
- pneumatic suction device,
- central lubrication.

A compressed air connection is required for this overlock to function properly.

A complete sewing machine, on the stand and PREMIUM tabletop of the renowned Kessler brand. The highest quality table top made of 30-layer birch plywood guarantees long life and resistance to working conditions. Covered with structural laminate with increased resistance to impact and abrasion.

For this machine we recommend SCHMETZ needles system B-27 with correct needle points, depending on the fabric.

The photo shows the machine recessed into the table top. Currently, the machine is mounted on the table top.

Close

ZOJE B9500-13-ED3-02 is 2-needle, 4-thread overlock for sewing light and medium fabrics. The sewing machine is equipped with automatic trimming, foot lifting and integrated, pneumatic suction for fabric leftovers.

Industrial overlock from the new ZOJE - V Generation .

Zoje industrial overlock

B9500-13-ED3-02 is a professional sewing machine with integrated scrap suction and automatic thread trimmer. This modern solution allows for more effective and easier maintenance of the machine, and thus the entire sewing room clean. Overlock B9500-13-ED3-02 sews with maximum speed 7 000 stitches per minute, the stitch width is 6 mm . In this model, the foot rises to a height of 6 mm. Sewing machine equipped with differential bottom feed and automatic functions: needle positioning, thread cutting and foot lifting . Zoje B9500-13-ED3-02 is an industrial overlock with an improved central lubrication system.

A modern two needle overlock

Model B9500-13-ED3-02 is equipped with an energy-saving AC SERVO motor. The control box, motor and direct drive of the needle bar are built into the head of the machine, what effectively reduces vibrations. Easy access to sewing parameters is provided by a clear control panel . The operation of the machine is additionally facilitated by voice messages . The field of work is illuminated by an energy-saving and precise LED lamp.

For overlock B9500-13-ED3-02 SCHMETZ system B-27 with the corresponding points.

Close

ZOJE B9500-13-ED3-02 SET is 2-needle, 4-thread overlock for sewing light and medium fabrics. The machine is equipped with automatic trimming, foot lifting and integrated, vacuum suction of fabric leftovers.

Industrial overlock from the new ZOJE - V Generation .

Zoje industrial overlock

B9500-13-ED3-02 SET is a professional sewing machine with integrated system of vacuum suction of fabric remnants into a special tank and electromagnetic thread trimmer. This modern solution allows for more effective and easier maintenance of the machine, and thus the entire sewing room clean. Overlock B9500-13-ED3-02 SET sews with maximum speed 7 000 stitches per minute, stitch width is 6mm . In this model, the foot rises to a height of 6 mm. Sewing machine equipped with differential bottom feed and automatic functions: needle positioning, thread cutting and foot lifting . Zoje B9500-13-ED3-02 is an industrial overlock with an improved central lubrication system.

A modern two needle overlock

The B9500-13-ED3-02 SET model is equipped with an energy-saving AC SERVO motor. The control box, motor and direct drive of the needle bar are built into the head of the machine, which effectively reduces vibrations. Easy access to sewing parameters is provided by a clear control panel . The operation of the machine is additionally facilitated by voice messages . The field of work is illuminated by an energy-saving and precise LED lamp.

ZOJE B9500-13-ED3-02 SET does not require compressed air for operation.


A complete sewing machine, on the stand and PREMIUM tabletop of the renowned Kessler brand.

For overlock B9500-13-ED3-02 SET we recommend needles SCHMETZ system B-27 with the appropriate points.

Close
